Filter Ball Valves

Our Filter Ball Valves are forged in hot brass to filter the system. Nickel-plated, End threaded to ISO 228 (DIN 259 BSP 2779). Provided with a steel handle, PVC covered. Individual or multiple packages.

To discuss your next project or for advice to find the right solution, call our technical advice team on 01530 519666 or send us an email.

Technical specifications

• Stainless steel filtering mesh: 0.5 mm.
• PN 16.
• Max Temperature 120°C.
• Size: 1/2”, 3/4”, 1”, 1”1/4 and 1”1/2

Kvs values:

• 1/2” : 5,3
• 3/4” : 5,6
• 1” : 12,0
• 1”1/4 : 20,0
• 1”1/2 : 40,0
